SoundConnect

Description

The SoundConnect eliminates hum problems when connecting audio from your presentation computer or other audio source.

Hum can be introduced anywhere, regardless of the distance you may be running your audio signal. Power supplies, fluorescent lights and all sorts of equipment can cause noise that is picked up by your audio input cables. It is designed to fit a standard XLR mounting (dia-22mm).

Main Features

– Stereo to Mono jumper selection
– 20dB pad switch allows audio to be input on either line or mic connection
– Earth (Ground) isolation ensures that ground loops are easily defeated
– Left/Right output on screw terminal Phoenix connectors
– Compact size
– No power required (passive) – Always ready to go
– Supplied 0.5m (19½”) mini jack to mini jack cable
– 3-Year Limited Factory Warranty

Specifications

Signals: Typical input 700mV p-p unbalanced stereo audio
Bandwidth: 200Hz to 14KHz. Signal levels depend on input level and output impedance
Control Switches:
– Stereo to Mono jumper selection depending on installation
– Output Pad from –2dB / -20dB
– Earth (Ground) lift
Connections:
– Input: 3.5mm mini jack socket
– Supplied 0.5m (19½”) mini jack to mini jack cable
– Screw terminal Phoenix connector
Dimensions mm (inch) LxWxD:
42(1 5/8″) x 42(1 5/8″) x 38mm(1½”)
(Allow extra clearance for cable connection at the base of the unit)
Weight: 22g / 0.8oz
Power: None required

More product information can be found here
